Introduction

Angiosarcomas (AS) are rare, usually aggressive soft tissue neoplasms which originate from endothelial cells. Primary breast AS (PBAS), although accounting for less than 0.1% of all malignancies, areone of the most common sarcomas. Risk factors include: trauma radiation; lymphoedema; breastimplants; xeroderma pigmentosum; neurofibromatosis; and vinyl chloride. Secondarybreast AS appears in older women, either following radiotherapy for breast cancer or due to chronic lymphoedema. The average time interval after radiotherapy is 10.5 years (1). The development of breast conservation therapy has caused an increasing incidence of secondary AS after adjuvant radiotherapy. PBAS is usually seen in women under 40 who have noprevious history of malignancy or other known risk factors. Between 6% and 12% of cases appear during pregnancy or shortly afterwards, suggesting hormonal involvement.

Primary and secondary breast AS have similar malignant behaviour and both carry a poor prognosis. PBAS generally arise within the parenchyma. PBAS is considered histologically and clinically distinct from radiation-induced breast AS. Secondary AS differ fromprimary AS in their pathogenesis by showing high level amplifications of: MYC proto-oncogene; fms-related tyrosine kinase 4 (FLT4); and vascular endothelialgrowth factor receptor 3 (VEGFR3) (2,3). This vascular endothelial growth factor stimulates cellular responsesby binding to tyrosine kinase receptors (VEGFRs) oncell surfaces, causing them to dimerize and activate through transphosphorylation (4). Hypoxia induciblefactor 1 (HIF-1) is a heterodimeric transcription factor; it is regulated by changes in cellular oxygenconcentration, growth factors, oncogenic activation, orloss of tumour suppressor function. Over expression ofHIF-1α can lead to the production of various hypoxiainducible mRNAs encoding VEGF, platelet-derivedgrowth factor B, erythropoietin, Galectin-3, andtransforming growth factor alpha (5). In addition, theover expression leads to the production of Wilmstumour protein WT-1, a protein capable of activatingvascular gene transcription (6).

PBAS initially presents as a painless, smooth, deep, mobile mass greater than 4 cm. 17% of cases include red discoloration and skin involvement (bluishoverlying skin discoloration). In contrast, secondary cases present as ill-defined or multifocal cutaneous patches or nodules. PBAS shows a poorer outcome than other histological types of primary breast sarcomas.

Mammograms and ultrasounds do not have pathognomonic characteristics in angio sarcomas. Diagnosing angiosarcomas prior to surgery, using fineneedle aspiration (FNA) or needle core biopsy (NCB) can be difficult and these procedures often cause excessive bleeding. Chen et al. reported apercutaneous biopsy false-negative rate of 37% (7).Surgical resection and microscopic examination of asample of the tumour are often necessary to confirm adiagnosis. Immunohistochemical examination (factorVIII and CD31 positivity) will confirm the vascularnature of the tumour (8).

Previous studies have reported a varied fiveyear overall survival rate (40% to 85%) (9). Certainfactors are commonly accepted as affecting the survival of patients with soft tissue sarcomas. These include pathologic grade, tumour size at diagnosis and margin status, of which pathologic grade is the most important factor. However, it is not clear that these are prognostic factors in breast AS.

Total mastectomy is the preferred surgical treatment (10). Chemotherapy and radiation therapymay be used as adjuvant treatment.

Half of AS are associated with metastaticdisease, with the metastasis occurring either atpresentation or developing subsequently during thecourse of the disease. The lungs and the liver are themost common metastatic sites, followed by lymphnodes, bone marrow and, less frequently, the ovaries,kidneys, omentum, the adrenal gland, the stomach,the pancreas, peritoneum, the oesophagus and the skin.

This case report follows a 28 year old woman who had previously undergone a total mastectomy due to a high grade PBAS. 20 months later she developed AS of the ovary and metastasis to the axilla. This is exceptionally rare. In previous studies, 100% ofcases reporting metastasis documented it occurring within the first year of diagnosis of a high grade PBAS (11).

Case report

A 28 year old woman was admitted to the gynecological emergency department complaining of abdominal pain. The patient’s past medical history included a radical right mastectomy 20 months previously, due to a poorly differentiated PBAS (T2aN0M0 G3), fibromyalgia and nuligesta. The patient was a smoker with a ten pack year history. Allergies included quinolones. This patient also had a relevant family history. A paternal aunt was diagnosed with breast cancer at the age of 50 and her maternal grandmother suffered from Hodgkin´s Lymphoma.

The PBAS was a rapidly growing lesion measuring 10 cm at diagnosis. After surgery it remained 2 cm from the nearest margin resection. The Ki67 protein had a value of 10%. She had animmediate breast reconstruction, using an expander implant, and six subsequent cycles of adjuvant chemotherapy. The chemotherapy regimen consistedof ifosfamide and epirubicin with granulocyte colonystimulating factor (G-CSF) support; it ended 15 months later. It was followed by adjuvant breast radiotherapy with a regimen of 50 Gy. The breast implant placement was carried out 14 months later.

The patient was hemodynamically stable on admission. On examination the patient had positive rebound tenderness in the right iliac fossa and hypogastrium. The Blumberg sign was positive andthere were positive bowel sounds.

An abdominal ultrasound reported adistended pouch of Douglas occupied by echogenic material; it might have corresponded to hematic material, suggesting the possibility of a rupturedcorpus luteum and a heterogeneous mass in the leftovary. A discrete amount of free fluid was detected.No signs of an appendicitis were detected.

A transvaginal ultrasound was performed anda solid vascularized neoplasm was found in the leftovary. A thoracic-abdominal-pelvic computed tomography (CT) with contrast revealed lymphadenopathy with punctuate calcifications in theright axillary region, the largest having a maximum diameter of 21mm. There were no pulmonary lesions, no hilar or mediastinal lymphadenopathy and noevidence of pleural effusion. The CT also revealed aleft ovarian mass. The mass was retrouterine inlocation with high density areas of heterogeneoustissue. The mass measured approximately 68x41x69mm in its transverse, sagittal and anteroposterior diameters respectively. Small amounts of free peritoneal fluid were present. There was no evidence of pelvic, retroperitoneal or mesenteric lymph nodes involvement, no focal lesions in the liver nor peritonea limplants. No bone lesions were seen. A pelvic nuclear magnetic resonance (NMR) with contrast was performed, revealing a solid tumour with a leftparauterine-retrouterine location measuring 85x38x62mm in its transverse, sagittal and anteroposteriordiameters respectively. It presented a heterogeneous signal intensity with multiple T1-hyperintense areas, compatible with areas of bleeding. After a contrastmedium was administrated, hyperintense necroticareas were detected. The findings described are most compatible with metastatic ovarian neoplasm.

The full blood count and coagulation screen were normal. Due to the finding of an ovarian neoplasm and the personal history of breast angiosarcoma, it was decided to perform anexploratory laparotomy. An intraoperative biopsy of the left adnexa revealed a malignant mesenchymal tumour. Consequently, stage surgery was completed with a total hysterectomy, right adnexectomy, appendectomy, inframesocolic omentectomy andpelvic and paraaortic lymphadenectomy.

The histological results were as follows: absence of neoplastic cells in the ascitic fluid and adiagnosis of angiosarcoma in the left ovary. The immunohistochemical study was positive for CD34 andCD31, negative for monoclonal antibody D2-40 andpan cytokeratin CK, with a high Ki67 (> 60%). It was anangiosarcoma with different degrees of differentiation figure 1). It had more than 20 mitoses/10 HPF (HighPower Field), very few foci of tumour necrosis and abundant lakes of hematic material.

This particular tumour did not affect the ovarian capsule. No tubal, appendix, contralateral ovary, omentum or pelvic or paraaortic node involvement was identified. It was there fore classed asa stage la ovarian angiosarcoma.

Treatment by paclitaxel chemotherapy (90mg/m2, 144mg weekly) was recommended at the weekly medical oncologist consultation. Examination showed a 4 cm hard and painful right axillary mass. A right axillary ultrasound revealed a 2.4x2.3cm solid, hypoechoic and lobulated mass, compatible with tumour recurrence. Three adjacent lymphadenopathies were identified whose sizes were m, 1.3 cm and 1.5 cm. An NCB was performed andthe histological findings were tumour necrosis and a positive immunohistochemical staining with markers CD34, CD31, FLI1 (figures 2 and 3) and ERG. Anangiosarcoma with a high rate of proliferation (highlevels of Ki-67) was the diagnosis.

Following the third cycle of chemotherapy with paclitaxel, the axillary mass measured approximately 2 cm. The patient was suffering from headaches. A neurological examination was performed and the findings were normal. A cranial CT with contrast revealed no evidence of metastatic disease. It was decided to continue with three more cycles of paclitaxel. A decreased axillary lymphadenopathymeasuring 1.5x0.8x1.7 cm was identified in a rightaxillary ultrasound. A smaller lymphadenopathy with ameasurement of 1.5x0.6x0.7 cm, similar to that in theprevious study was also diagnosed. A thoracicabdominal-pelvic CT with contrast was requested for reassessment. It revealed a hypervascular nodule in the 4th left hepatic lobe segment, remaining stablewith a decreased axillary adenopathy. On the fourth cycle of chemotherapy a clinical progression of the axillary lymph node measuring 4cm was diagnosed. Results of thoracic-abdominal-pelvic CT with contrast was similar to the previous one, except for an increasefrom 1.0 cm to 1.8 cm in the size of the right axillary adenopathy in the short axis in the axial plane. The patient was referred to the Breast Cancer Unit.

Examination in the Breast Cancer Unit revealed a 4 cm right axillary nodule attached the pectoralis major muscle. A necrotic hypoechoic adenopathy with irregular and lobulated contours was identified in a right axillary ultrasound; it was smaller than in the previous study, measuring 1.5x0.8x1.7 cmin its transverse, craniocaudal and anteroposterior axes. These findings were suggestive of tumourrecurrence. A further lower adenopathy, located nextto the side edge of the breast prosthesis, wasidentified; it was of similar appearance to that in the previous study, with a size of 1.5x0.6x1.3 cm. An MRN was requested to assess infiltration of the pectoral region. It revealed intracapsular rupture of the right breast, a retropectoral prosthesis in the upper outer quadrant and a large right axillary adenopathic mass of 6x3 cm.

Due to these findings an axillary clearance and breast prosthesis replacement were performed. The histopathology of axillary dissection identified metastatic angiosarcoma with several tumour nodules,the largest measuring 3 cm; some tumours were found very close to the resection margins.

The case was presented to the Breast Cancer Committee. Here it was decided not to extend surgery,in accordance with the evaluation of the Sarcomas Committee of the referral hospital. Currently the patient is being monitored by the Medical Oncology Department and has an appointment for a CT and reassessment.

Discussion

PBAS is a rare tumour derived from endothelial cells. It is usually seen in young women of child bearing age who have no previous cancer history or other known risk factors.

It is usually diagnosed as a painless smooth deep mass greater than 4 cm, with a rapid growth. In this case the tumour measured 10cm at diagnosis. Large masses have previously been reported as leading to platelet sequestration and disseminated intravascular coagulation and hemorrhagic manifestations of Kasabach Merritt syndrome. Infrequently the patient presents with nipple retraction, discharge or axillary lympadenopathy.

On mammograms, angiosarcoma is identified as a mass without spiculation, microcalcification o rlympadenopathies. In a review of radiologic findings with angiosarcomas, Liberman et al. (12) established that echotexture of these lesions is highly variable.They conclude that breast X-rays may appearcompletely normal in about 33% of cases but patients with higher grade lesions have abnormal mammograms with a higher probability (12). Multiple studies have shown the ability of NMR to identify patterns of malignancy in angiosarcoma (low signalintensity on T1-weighted images, hyperintensity on T2images and a rapid initial intense phase followed by washout MRI) (13).

In histological and immunohistochemical diagnosis, the marker CD31 is considered to be the most sensitive and the most specific indicator of angiogenic proliferation. The lesions will also stain positive for the vascular markers factor VIII, FLI1 and for CD34 (8). The immunohistochemical study in this case was positive for CD31 and CD34, negative for D2-40 and pan CK, with a high Ki67 (> 60%), a proliferation marker. Data indicating levels of WT-1 were unavailable. The presence of progesterone oroestrogen receptors were not confirmed. Manyauthors have reported primary angiosarcomas to bewell differentiated, with histological features sometimes mimicking benign lesions.

Pathologically, these tumours are subdivided into three groups according to the classification proposed by Donnell et al. (14). The groups are gradedas follows. Grade 1 tumours are well differentiated and contain open anastomosing vascular channels that proliferate within dermis, subcutaneous or breasttissue. These channels contain a single layer of endothelial cells, which dissect through the stroma, causing distortion but little destruction of the preexisting lobules and ducts. Grade 2 (intermediat egrade) angiosarcomas differ from low-grade tumoursby containing additional cellular foci. These can formof papillary formations or solid and spindle cell proliferation. The greater part of the tumour, however, is still composed of low-grade histology. Slightly increased mitotic activity is observed. In grade 3 angiosarcoma endothelial tufting and papillary formations are prominent. Conspicuous solid and spindle cell areas, without vascular formations, are also present. Mitoses may be brisk, especially in more cellular areas. Areas of hemorrhage, known as “bloodlakes”, and necrosis can also be seen.

The correlation between tumour size andprognosis is controversial. Sher et al (15), found no correlation between the size of the primary tumourand the risks of recurrence or death. On the contrary, Zelek et al (16), Depla et al (17) and others underlinedan association between tumour size and disease-freesurvival. Five years after initial treatment the estimated probability of disease-free survival is 76%for patients with Grade 1 tumours; compared to 15%for patients with Grade 3 tumours. There is no precisecorrelation, however (18). Tumours smaller than 5 cmare usually associated with a better prognosis (15).

In clinical practice, large tumour size (> 5 cm), high histologic grade, vascular invasion and positive margins were generally accepted as factors that predicted high recurrence and poorer survival rates. Inthis case the tumour was poorly differentiated (Grade3). It measured more than 5 cm at diagnosis but later metastasized to the ovary and had an axillary recurrence 20 months after the first diagnosis.

Radical surgical en bloc resection with negative margins (R0) is the primary therapy for a potentially curable localised disease (17).

Since hematogenous dissemination is very common, axillary node dissection is not indicated (15). Due to its infrequency, there are no randomised controlled trials comparing breast conserving approaches with mastectomy. Breast conserving therapy has been used but it is only recommended fors mall lesions of Grade 1 where there is an excellentchance of achieving R0. Radical mastectomy with clearsurgical treatment was appropriate in our case because it was a large poorly-differentiated tumour.

Adjuvant therapy is beneficial to patients witha high risk of recurrence. There is still debate in the literature regarding histologic grade as a prognostic factor and therefore for advising adjuvant therapy (14). The role of adjuvant chemotherapy is ill defined, because of the rarity of PBAS and the lack ofprospective studies (15). Some studies suggest that treatment with anthracycline-based chemotherapy may improve both disease-free survival and overall survival. In a more recent study of 41 cases ofmetastatic angiosarcoma treated with taxane regimens, Hirata et al showed an improvement inoverall survival rates (19). Our patient underwent fourcycles of paclitaxel for metastatic angiosarcoma; it wasstopped for axillary dissection.

In a report published by Sher et al (14), adjuvant chemotherapy using combinations ofanthracycline–ifosfamide or gemcitabine–taxane did not reveal any improvement in disease-free survival. However, administration of chemotherapy at the time of recurrence resulted in a response rate of 48% (14).A meta analysis of patients treated in a randomized controlled trial with doxorubicin, epirubicin and ifosfamide demonstrated longer disease-free survival and overall survival (20). This was the chemotherapy regimen used for PBAS in our case.

In the majority of cases where chemotherapy was used, most authors prescribe cyclophosphamide, anthracycline or an alkylating agent combined with apyrimidine analogue. Some clinical trials demonstrated that doxorubicin-based regimens and paclitaxel are two of the most active agents (21).

A success rate of 84% was reported when the adjuvant treatment was combined with TNF-α and IFN-α. The results were variable, when using bevacizumab, an anti–vascular endothelial growth factor antibody. Currently two phase II clinical trials are investigating the use of bevacizumab in cases of sarcoma, including angiosarcoma.

Since there is a high likelihood of locoregional recurrence, radiation therapy is proposed after a total mastectomy. It has been suggested that radiation therapy may improve the outcome for patients following surgical resection. Especially for patients with microscopically positive margins (10, 15). Despite surgical margins after a radical mastectomy and adjuvant breast radiotherapy, our patient had anaxillary recurrence 20 months later, revealing themalignant potential of this tumour.

Half of angiosarcomas are associated with metastatic disease, either at presentation or at asubsequent point in the disease. Several case series have shown that these tumours most of tenmetastasize to the liver, lungs or bones. Of the verifiable reports of ovarian metastases, all were found at post mortem as widely disseminated.

To our know ledge, there have been only four confirmed previous cases of PBAS metastasizing predominantly to the ovary (22). Inoperable, locally advanced or metastatic angiosarcoma is treated bycytotoxic chemotherapy. Recent investigations havelooked at aberrant molecular or gene changes in PBAS.These results may offer hope for a specific target therapy in the future (23, 24).

Conflict of interest

The study has been approved by a research ethics committee and there are no conflicts of interest to declare.

References

1. Young RJ, Brown NJ, Reed MW, Hughes D, Woll PJ. Angiosarcoma. Lancet Oncol. 2010; 11:983–91. [PubMed] [GoogleScholar]

2. Guo T, Zhang L, Chang NE, Singer S, Maki RG, Antonescu CR. Consistent MYC and FLT4 gene amplification in radiationinduced angiosarcoma but not in otherradiation-associated atypical vascularlesions. Genes Chromosom Cancer. 2011; 50:25–33. [PubMed] [Google Scholar]

3. Manner J, Radlwimmer B, Hohenberger P,Mossinger K, Kuffer S, Sauer C,Belharazem D, Zettl A, Coindre JM,Hallermann C, Hartmann JT, KatenkampD, Katenkamp K, Schöffski P, Sciot R,Wozniak A, Lichter P, Marx A, Ströbel P.MYC high level gene amplification is adistinctive feature of angiosarcomas afterirradiation or chronic lymphedema. Am J Pathol. 2010; 176:34–9. [PubMed][Google Scholar]

4. Holmes K, Roberts OL, Thomas AM, CrossMJ. Vascular endothelial growth factorreceptor-2: structure, function, intracellular signalling and therapeuticinhibition. Cell Signal. 2007; 19:2003–12.[PubMed] [Google Scholar]

5. Greijer AE, van der Groep P, Kemming D, Shvarts A, Semenza GL, Meijer GA, van deWiel MA, Belien JA, van Diest PJ, van der Wall E. Upregulation of gene expressionby hypoxia is mediated predominantly byhypoxia-inducible factor 1 (HIF-1). J Pathol. 2005; 206:291–304. [PubMed][Google Scholar]

6. Kirschner KM, Sciesielski LK, Scholz H.Wilms’ tumour protein Wt1 stimulatestranscription of the gene encodingvascular endothelial cadherin. Pflugers Arch. 2010; 460:1051–61. [PubMed][Google Scholar]

7. Chen KTK, Kirkegaard DD, Bocian JJ.Angiosarcoma of the breast. Cancer.1980; 46: 368–71. [PubMed] [GoogleScholar]

8. Bennani A, Chbani L, Lamchahab M, Wahbi M, Alaoui FF, Badioui I, MelhoufMA, Amarti A. Primary angiosarcoma ofthe breast: a case report. Diagn Pathol. 2013; 8:66. [PubMed] [Google Scholar]

9. Luini A, Gatti G, Diaz J, Botteri E, Oliveira E, Cecilio Sahium de Almeida R, Veronesi P, Intra M, Pagani G, Naninato P, Viale G. Angiosarcoma of the breast: the experience of the European Institute of Oncology and a review of the literature. Breast Cancer Res Treat 2007; 105:81–5. [PubMed] [GoogleScholar]

10. Kaklamanos IG, Birbas K, Syrigos KN, Vlachodimitropoulos D, Goutas N, Bonatsos G. Breast angiosarcoma thatis not related to radiation exposure: acomprehensive review of the literature. Surg Today. 2011; 41:163–8. [PubMed][Google Scholar]

11. Hu QC, Mei X, Feng Y, Ma JL, Yang ZZ, Shao ZM, Yu XL, Guo XM. Managementexperiences of primary angiosarcomaof breast: a retrospective study fromsingle institute in the People’s Republicof China. Onco Targets Ther. 2015:83237–3243. [PubMed] [Google Scholar]

12. Liberman L, Dershaw DD, Kaufman RJ, Rosen PP. Angiosarcoma of the breast. Radiology 1992; 183:649–654.[PubMed] [Google Scholar]

13. Yang WT, Hennessy BT, Dryden MJ, Valero V, Hunt KK, Krishnamurthy S. Mammary angiosarcomas: imagingfindings in 24 patients. Radiology. 2007; 242: 725–34. [PubMed] [GoogleScholar]

14. Donnell RM, Rosen PP, Liberman PH. Angiosarcoma and other vasculartumors of the breast. Am J Surj Pathol.1981; 5:629–42. [PubMed] [GoogleScholar]

15. Sher T, Hennessy BT, Valero V, BroglioK, Woodward WA, Trent J, Hunt KK, Hortobagyi GN, González-Angulo AM.Primary angiosarcomas of the breast. Cancer. 2007; 110: 173–8. [PubMed][Google Scholar]

16. Zelek L, Llombart-Cussac A, Terrier P, Pivot X, Guinebretiere JM, Le PechouxC, Tursz T, Rochard F, Spielmann M, LeCesne A. Prognostic factors in primarybreast sarcomas: a series of patientswith long-term follow-up. J Clin Oncol. 2003; 21: 2583–8. [PubMed] [GoogleScholar]

17. Depla AL, Scharloo-Karels CH, de Jong MA, Oldenborg S, Kolff MW, Oei SB, van Coevorden F, van Rhoon GC, BaartmanEA, Scholten RJ, Crezee J, van TienhovenG. Treatment and prognostic factors ofradiation-associated angiosarcoma (RAAS) after primary breast cancer: a systematicreview. Eur J Cancer. 2014; 50:1779–88. [PubMed] [Google Scholar]

18. Rosen PP, Kimel M, Ernsberger D.Mammary angiosarcoma. The prognosticsignificance of tumor differentiation. Cancer. 1988; 62:2145–51. [PubMed][Google Scholar]

19. Fayette J, Martin E, Piperno-Neumann S, Le Cesne A, Robert C, Bonvalot S, Ranchère D, Pouillart P, Coindre JM, BlayJY. Angio sarcomas, a heterogeneous group of sarcomas with specific behavior depending on primary site: aretrospective study of 161 cases. Ann Oncol. 2007; 18:2030–6. [PubMed][Google Scholar]

20. Hirata T, Yonemori K, Ando M, HirakawaA, Tsuda H, Hasegawa T, Chuman H, Namikawa K, Yamazaki N, Fujiwara Y.Efficacy of taxane regimens in patientswith metastatic angiosarcoma. Eur JDermatol. 2011; 21: 539–45. [PubMed][Google Scholar]

21. Pervaiz N, Colterjohn N, Farrokhyar F, Tozer R, Figueredo A, Ghert M. Asystematic meta-analysis of randomizedcontrolled trials of adjuvantchemotherapy for localized resectablesoft-tissue sarcoma. Cancer. 2008; 113:573-81. [PubMed] [Google Scholar]

22. Souza FF, Katkar A, den Abbeele AD, Dipiro PJ. Breast angiosarcoma metastaticto the ovary. Case Rep Med. 2009; 2009: 381015 [PubMed] [Google Scholar]

23. Italiano A, Cioffi A, Penel N, Levra MG,Delcambre C, Kalbacher E, Chevreau C,Bertucci F, Isambert N, Blay JY, Bui B,Antonescu C, D'Adamo DR, Maki RG,Keohan ML. Comparison of doxorubicinand weekly paclitaxel efficacy inmetastatic angiosarcomas. Cancer. 2012; 118: 3330-6 [PubMed] [Google Scholar]

24. Silva E, Gatalica Z, Vranic S, Basu G, ReddySK, Voss A. Refractory anigosarcoma ofthe breast with VEGFR2 upregulationsuccessfully treated with sunitibib. Breast J. 2015; 21:205–7. [PubMed] [GoogleScholar

Author notes

Jorge Cea García. 9 Almensilla St, 41.008, Seville, Spain. Telephone number: +34651367773. Email: jor_cea@hotmail.com
