Comet assay to determine genetic damage by the use of ivermectin in zebu cows (Bos taurus indicus)

Determinación mediante prueba cometa del daño genético causado por uso de ivermectina en vacas cebú (Bos taurus indicus)

Donicer Montes-Vergara
Universidad de Sucre, Colombia
Jaime De la Ossa V
Universidad de Sucre, Colombia
Alexander Pérez- Cordero
Universidad de Sucre, Colombia

Comet assay to determine genetic damage by the use of ivermectin in zebu cows (Bos taurus indicus)

Revista MVZ Córdoba, vol. 22, no. 2, pp. 5959-5965, 2017

Universidad de Córdoba

Abstract: Objective. The objective of the work was evaluate the damage genetic caused by the use of ivermectin (IVM) in cows zebu to concentrations of 1% and 3.15% through the test comet. Material and methods. 15 cows, were taken with age between 3 and 4 years old, average weight of 350 kg, body condition between 3 and 3.5. Three experimental groups with five animals per group, which were exposed to the concentration of IVM to 1% to 3.15% more group control (without application of IVM) were used. Animal blood sample was performed by venipuncture jugular or medial flow with vacutainer® needle, extracting 8 ml of blood. The blood samples it was collected at 9, 18 and 27 days post-treatment. Results. The display of the comets is made by using fluorescence microscope, the cells were evaluated by means of visual log and the Comet image software. Evidenced the presence of nuclei with DNA migration in all analyzed plates. The values of classification of comets indicate cells with high levels of damage (grade 3: cells with high damage). The rate of DNA damage of the treatment to 1% to 3.15% was significant, to relate to the control group. Conclusions. The results obtained in this study demonstrate the likely genotoxic potential of the use of IVM in cattle.

Keywords: Genetic damage, ADN, mammals, drug (Source: CAB).

Resumen: Objetivo. El objetivo del trabajo fue evaluar el daño genético causado por el uso de Ivermectina (IVM) en vacas cebú (Bos taurus indicus). Materiales y Métodos. Se tomaron quince vacas, con edad entre tres y cuatro años, peso promedio de 350 kilogramos, condición corporal entre 3 y 3,5. Se utilizaron tres grupos experimentales con cinco animales por grupo, los cuales se expusieron a la concentración de IVM al 1% y 3,15% más un grupo control (sin aplicación de IVM). La muestra sanguínea por animal fue realizada mediante punción venosa yugular o caudal medial con aguja para vacutainer ®, extrayéndose 8 ml de sangre. Las muestras sanguíneas fueron recolectadas a los 9, 18 y 27 días postratamiento. Resultados. La visualización de los cometas se realizaron con microscopio de fluorescencia, las células fueron evaluadas por medio de registro visual y por el software Comet Imagen. Se evidenció la presencia de núcleos con migración de ADN en todas las placas analizadas. Los valores de clasificación de los cometas, denotaron células con altos niveles de daño alto (grado 3). El índice de daño del ADN de los tratamientos al 1% y 3,15% fue significativo, al relacionarlo con el grupo control. Conclusión. Los resultados de este estudio evidenciaron el probable potencial genotóxico del uso de la IVM en ganado vacuno.

Palabras clave: Daño genético, ADN, mamíferos, fármaco (Fuente: CAB).

INTRODUCTION

The use of chemical products to keep cattle healthy and with high yields is based on the need to meet the growing demand for animal products worldwide. Drugs are routinely and prophylactically applied to animals for the treatment of parasitic diseases. There is little knowledge of studies on the genotoxicity (defined as DNA damage) and/or cytotoxicity of IVM in individuals (vectors, mammals and humans), which is available for parasite control (1,2 ). However, there is a lot of in vivo literature associated with the evaluation of forms of administration, therapeutic doses (3), sensitivity of invertebrates to the drug (4) and resistance (5,6).

To detect the genotoxic damage caused by various agents, different tests can be used that determine alterations caused to genetic material, in both somatic and germ cells. The Comet or Single Cell Gel Electrophoresis (SCGE) assay detects single and double-stranded DNA damage, allowing for the evaluation of DNA fractionation and repair levels in cell populations without the need to work with proliferating cells. The name derives from the appearance of cells after the test: an intensely bright head and a tail whose length and intensity are related to the amount of chain breaks in the DNA. In contrast, undamaged cells have intact nuclei without tails (7).

All living things are directly or indirectly exposed, not only to the active components of pesticides, but also to their commercial formulation. They include mixtures of one or more active substances with toxic activity and a theoretically biologically inert excipient. However, numerous in vitro and in vivo studies have shown that, in most cases, the potential risks to which living organisms are exposed from commercial formulations are more damaging than the active compounds. The objective of this study was to evaluate the genetic damage caused by the use of Ivermectin (IVM) in zebu cattle (Bos taurus indicus).

MATERIALS AND METHODS

Population study. Fifteen Cebu Brahman cows were used, between three and four years of age, with an average weight of 350 kg, body condition of between 3.0 and 3.5 and a good health status. The livestock belonged to the cattle on the Cielo Lindo Hacienda, located in the rural area of the municipality of Corozal, in the northeast region of the Department of Sucre (Colombia). This hacienda is located at an altitude of 174 masl, with an average temperature of 30ºC and precipitation of 1,300 mm. The selected animals were kept in quarantine for more than seventy days, with no supply of medication before the start of the study.

Experiment group. A unifactorial experiment design was used, with three experiment groups, each with five animals. The first group was exposed to 1% IVM concentrations. The second group was exposed to 3.15% IVM concentrations, and the third group was the control (without an IVM application). The IVM doses corresponded to those formulated by the commercial products and their application followed the biosecurity protocols established on the hacienda. To evaluate the possible difference between the treatments and control, a one-way variance (ANOVA) analysis and multiple comparison tests of n-treatment means were performed with a Dunnett control to compare the treatments with the control, without IVM. Statistical analyzes were performed using free access software R (8).

Collection of samples. The blood samples were collected at 9, 18 and 27 days post-treatment with jugular vein punctures, caudal or medial, collected in Vacutainer® tubes with EDTA (anticoagulant). 8 ml of whole blood was drawn.

The samples were processed in the microbiology laboratory of the Universidad de Sucre using the comet test technique, according to the protocol of Singh et al (7), as modified by Ramírez and Cuenca (9). The parameters validated to determine the damage assessed by the comet test included: DNA migration, DNA concentration in the tail, tail moment, and Olive moment (10). For this study, the tail length (μm) was used as the measurement parameter (11,12). The criterion for determining genetic damage was the mean of the control plus a standard deviation plus one (X ± SD + 1) and, according to this value, the type of damage was classified into five categories: 0: -18 μm); 1: cells with low damage (19-37 μm); 2: cells with medium damage (38-56 μm): 3, cells with high damage (57-75 μm) and 4: cells with total damage (greater than 75 μm). (13).

The total damage count was calculated using the Damage Index (DI) technique, calculated as: DI = Σ PDD x DD, where DD is the degree of damage (from 0 to 4) and P is the percentage of cells that show damage. For each individual, 100 cells per plate (total two plates) were analyzed. The images of the comets were photographed and analyzed with the Open Comet program (14).

Complementary material - Comet test. Cells were suspended in 0.5% low melting agarose (PML) in PBS and pipetted onto previously coated slides with a 1% normal melting point (NMP) agarose layer. Cell suspension slides were placed on cover-slips and brought to 4°C for ten minutes, then submerged in lysis buffer (2.5 M NaCl, 100 mM Na 2 EDTA, 10 mM Tris-HCl pH 10, 1% Triton X-100 and 10 % DMSO) for one hour at 4°C in the dark to allow lysis of the embedded cells and unwinding of the DNA. After incubation of the cells in the lysis solution, the slides were exposed to an alkaline buffer solution (1mM Na 2 EDTA, 300 mM NaOH buffer), pH> 13, for twenty minutes to degrade the DNA. Finally, the slides were electrophoresed for twenty minutes at 25v and 300mA in the same alkaline buffer (pH> 13), after which the slides were washed with 0.4 Tris-HCl buffer (pH 7.5) to neutralize the excess alkali and remove detergents. Finally, the plates were fixed with ethanol, stained with ethidium bromide (1ug/ml) and examined under a fluorescent microscope at a 40X magnification.

RESULTS

Regardless of the IVM concentration, the presence of nuclei with DNA migration (Figure 1a and b) was observed at a percentage greater than 75% in all cells observed per plaque, demonstrating the ability of the IVM compound to produce simple chain breaks in the DNA molecule. The comet classification values denoted cells with high levels of damage (Grade 3-cells with high damage).

Optical microscopy, with 40 X magnification (a) and (b), nuclei with fragmented DNA. (c), nuclei without fragmented DNA.
a) T1= Concentración de IVM al 1%; b) T2= Concentración de IVM al 3.15%; c) T0= Sin aplicación de IVM
Figure 1
Optical microscopy, with 40 X magnification (a) and (b), nuclei with fragmented DNA. (c), nuclei without fragmented DNA. a) T1= Concentración de IVM al 1%; b) T2= Concentración de IVM al 3.15%; c) T0= Sin aplicación de IVM

Genetoxic damage caused by the IVM, evaluated with the damage index
Table 1
Genetoxic damage caused by the IVM, evaluated with the damage index

The mean length of the tail of the 1% and 3.15% treatments was 62.9 ± 6.8 μm and 69.2 ± 4.5 μm, respectively, significant (p<0.01) when compared to the control group (10.8 ± 3.2 μm) (Table 1). The mean damage index seen on the sampling day (9, 18 and 27) was not significant according to the Dunnett test.

DISCUSSION

For many years, IVM has been the best-selling antiparasitic drug in the world, but little is known about the genotoxic potential. The results of this research demonstrate the ability of IVM to induce single-strand breaks in DNA, which were evaluated using the comet assay methodology (Figure 1). The concentrations of IVM significantly increased the frequency of damaged cells, together with an increase in the amount of migrated DNA, as compared to negative control values (Table 1). In vitro, González et al (15) analyzed the deleterious capacity of IVM and one of its commercial formulations with a genotoxic assay. The results showed that both compounds exert a genotoxic and cytotoxic effect when exposed to equimolar concentrations of the active compound in a range of 5.0 to 50 μg/ml, inducing single strand breaks in the DNA molecule. On the other hand, in situ assays, as reported by Montes et al (16), demonstrated that concentrations IVM of 3.15% produced nuclei with DNA migration, corroborating the results of this study.

The results found in the present study constitute concrete evidence for the induction of genomic damage as exerted by IVM, using the comet assay methodology, which has been widely used to detect genomic lesions that are possibly corrected, once DNA damage is common in specific cells and tissues (17,18,19).

In conclusion, the results suggest that the genetic damage found in the studied livestock may be associated with the use of IVM; however, a single bioassay is insufficient as an indicator to characterize the toxicity of a studied pesticide study.

REFERENCES

1. Sturchio J, The case of ivermectin: lessons and implications for improving accesto care and treatment in developing countries. Comm. Eye Health 2001; 14(38):22-23.

2. Rodríguez M, Katholi CR, Hassan HK, Unnasch TR. Large-scale entomologic assessment of Onchocerca volvulus transmission by poolscreen PCR in México. Am J Trop Med Hyg 2006; 74(2):1026-1033.

3. Lifschitz A, VirkeL G, Ballent M, Sallovitz J, Imperiale F, Pis A, et al. Ivermectin (3.15%) long-acting formulations in cattle: absorption pattern and pharmacokinetic considerations. Vet Parasitol 2007; 147(1):303-310.

4. Intapan PM, Prasongdee TK, Laummaunwai P, Sawanyawisuth K, Singthong S, Maleewong W. Amodified filter paper culture technique for screening of Strongyloides stercoralis ivermectin sensitivity in clinical specimens. Am J Trop Med Hyg 2006; 75:763-564.

5. Kane NS, Hirschberg B, Qian S, Hunt D, Thomas B, Brochu R, et al. Drug- resistant Drosophila indicate glutamate-gated chloride chanels are targets for the antiparasitics nodulosporic and ivermectin. Proc Natl Acad Sci 2000; 97:13949-13954.

6. Fiel CA, Samuell CA, Steffan PE, Rodríguez EM. Resistance of cooperia to ivermectin treatments in grazing cattle of the humid pampa, Argentina. Vet Parasitol 2001; 97:211-217.

7. Singh NP, Mccoy MT, Tice RR, Schneider EL. A simple technique for quantitation of low levels of ADN damage in individual cells. Exp Cell Res 1988; 175:184-191.

8. R Development Core Team. R: A Language and Environment for Statistical Computing. The R Foundation for Statistical Computing; Vienna, AUT; 2015.

9. Ramírez V, Cuenca P. DNA damage in female workers exposed to pesticides in banana plantations at Limon, Costa Rica. Rev Biol Trop 1998; 50:507-518.

10. Ejchart A, Sadlej-Sosnowska N. Statistical evaluation and comparison of comet assay results. Mutat Res 2003; 534:85-92.

11. Uhl M, Helma C, Knasmüller S. Single cell gel electrophoresis assays with human-derived hepatoma (HepG2) Mutat Res 1999; 441:215-224.

12. Brink A, Schulz B, Kobras K, Lutz WK, Stoppe H. Time-dependent effects of sodium arsenite on DNA breakage and apoptosis observed in the comet assay. Mutat Res 2006; 603:121-128.

13. Ortiz IC, Pelaez CA, Orozco LY, Zuleta M. Interacciones genotóxicas de mutágenos en mezclas binarias mediante ensayo cometa alcalino en linfocitos humanos. Biomed 2012; 32:437-448.

14. Gyori BM, Venkatachalam G, Thiagarajan PS, Hsu D, Clement MV. Open Comet: an automated tool for comet assay image analysis. Redox Biol 2014; 2:457-65.

15. González NV, Molinari G, Solones S, Larramendy ML. Genotoxicidad y citotoxidad de pesticidas. Evaluación de los principios activos y formulaciones comerciales usadas en Argentina. Theori 2008; 17(2):27-45.

16. Montes VD, Montero Y, Roosi A, González H. Determinación de la genotoxicidad de la ivermectina a través del ensayo cometa. Rev Colomb Cienc Anim 2011; 3:321-327.

17. Collins AR. The comet assay for DNA damage and repair: principles, applications, and limitations. Mol Biotechnol 2004. 26:249-261.

18. Speit G, Rothfuss A. The comet assay: a sensitive genotoxicity test for the detection of DNA damage and repair. DNA Repair Protocols. Bjergbaek, L. editor. NY, USA; Springer-Media Busines Media: 2012.

19. González TJ, Moreno RA, Quintana SM. Efecto genotóxico de las mezclas complejas de hidrocarburos en trabajadores de estaciones de servicio de gasolina. Salud Uninorte 2015; 31:91-100.
